Case Type |
|
Material |
- Steel T1.0 ,Tempered Glass T4.0
|
Product Dimension ( H x W x D ) |
- 500×230×500mm, 19.7"×9.1"×19.7"
|
Drive Bay |
|
M/B Compatibility |
- E-ATX(12"×13"), ATX, Micro-ATX, Mini-ITX
|
Power Supply |
- PSII : ATX 12V(Length < 220 mm)
|
I/O Ports |
- USB 3.0 x 2 , USB 2.0 x 2 , HD Audio(CTIA-SPK/MIC ) , Type – C USB3.1 Gen .2
|
Expansion Slots( Maximum Space) |
- PCI-E x 7:Length <400mm(No Cooling of bottom) / Width <175mm
- Lateral PCI-E x 3:Length <412mm(No Cooling of bottom) / Width <150mm ( CPU Heatsink Height<105mm) / Height<65mm
|
Thermal Solution |
- Top : 120mm Fan x 1120mm Radiator
- Rear : 120/140mm Fan x 3 420mm Radiator( Length <470mm / Thickness < 55mm )
- 360/280mm Radiator ( Length <400mm / Thickness < 65mm )
- Bottom : 120/140mm Fan x 3 360/280mm Radiator ( Length < 485mm )
|
CPU Heatsink |
|
