main spec |
Dimensions |
485 x 241 x 504mm(DWH) |
Form Factor |
Mid Tower |
Materials |
Steel + Plastic + Glass |
Mainboard Support |
E-ATX (≤ 272mm), ATX, M-ATX, ITX |
Front Access & Controls |
Power, LED Control Button, USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack |
Side Panel |
4mm Tempered Glass |
|
Drive Bays |
Expansion Slots |
7 |
3.5" / 2.5" |
Normal M/B: 3/3
M-ATX Back Connect: 3/3
ATX Back Connect: 2/2 |
2.5" |
Normal M/B: 2
M-ATX Back Connect: 1
ATX Back Connect: 1 |
|
Fan Support |
Top |
3 x 120 / 2 x 140mm |
Side |
3 x 120mm |
Power Supply Shroud |
3 x 120mm |
Rear |
1 x 120 / 1 x 140mm |
Included Fan(s) |
3 x 120mm ARGB PWM reverse fans on right side + 1 x 140mm ARGB PWM fan in rear |
|
Radiator Support |
Top |
120 / 140 / 240 / 280 / 360mm |
Side |
120 / 240 / 360mm |
Rear |
120 / 140mm |
|
Clearance |
Max GPU Length |
≤ 450mm
(When overall AIO thickness > 52mm, the length of the graphics card is limited to 280mm.) |
Max CPU Cooler Height |
≤ 180mm |
Max PSU Length |
(Include cable) ≤ 210mm |
|
Miscellaneous |
Dust Filter |
Front / Left Side / Bottom |
Net Weight |
11.7Kg |
Gross Weight |
14.2Kg |
Warranty |
2Years |
UPC# |
0-761345-10135-6 |
|
