a. Left side LED – Switching Layers (Pn + N, M, <, >)
None - Default
Red - Layer 1
Green - Layer 2
Blue - Layer 3
b. Right side LED – Switching layout and Windows lock
Red - COLEMAK
Green - DVORAK
Blue – Windows lock None – QWERTY (Default)
4. Other functions:
a. Reset the current layer key-codes: Pn + R
b. Reset all layers’ key-codes and restore to default: L_Alt + R_Alt
c. Swap Fn or Pn position:
Hit Fn + L_Shift for 3 seconds then select new Fn key directly
Hit Pn + L_Shift for 3 seconds then select new Pn key directly
Bluetooth Pairing Guide
The following procedure details how to pair with your device.
To put your keyboard in pair mode, slide the power switch on (Back of case)
Activate Bluetooth on your device and set it to search for new devices.
Press Pn + L_Alt to enter the Bluetooth pairing mode, then hit Pn + one of J, K, L, ; to pair
Locate the list of Bluetooth devices in the interface of the device. After selecting "Vortexgear" from it, the Bluetooth indicator is off and the pairing is completed.
To pair second device or to re-pair to the original device: Same as Step 2 and 3
Remark:
Please use AAA battery x 2..
The Bluetooth indicator will flash Green quickly when switching groups
Low voltage shows a Red light
The USB mode is automatically switched when the USB is powered on.
