4 built-in lighting effect (Rainbow, Comet, Starry night and Logo lighting in RED)*
* Please note can only change the built-in effect while Aura or Halo software is off
Contents
1 x QSG
2 x 30cm ROG addressable RGB strips
1 x 60cm ROG addressable RGB strip
3 x extension cables
1 x 45W power adapter
1 x DC to MOLEX cable
1 x Micro USB to USB 2.0 Type-A data cable
1 x Micro USB to 9-pin header data cable
3 x packs of 3M double-sided tape (5cm)
1 x ROG stickers
2 x ROG cable ties
Dimentions
L 100 X W 70 X H 20 mm
Inputs
USB 2.0 CONNECTION FOR DATA:
- USB 2.0 9-pin header cable for internal case lighting.
- USB 2.0 Type-A cable for external case lighting.
12V/19V DC INPUT FOR POWER:
- 12V 4-pin molex to DC adapter cable for internal case lighting.
- 19V DC power adapter for external case lighting.
Outputs
4 channel addressable RGB*
* The addressable RGB header supports WS2812B addressable RGB LED devices (5V/ Data/ Ground), and each channel with a max of 90 LEDs and total channels support a max of 210 LEDs.
Hardware Requirements
PSU with a free Molex socket.
PC with a free USB port or free USB 2.0 header.
Minimum System Requirement
AURA:
- OS: Windows® 7/ Windows® 8/ Windows® 10
HALO:
- OS: Windows® 10 64-bit
- Graphics: Dedicated VGA*
* HALO does not support intergrated graphics (iGPU). Please connect your display to a DP/HDMI port located on your VGA card.
Recommended System Requirement
AURA:
- OS: Windows® 10 64-bit
HALO:
- OS: Windows® 10 64-bit
- Processor: 6th Generation Intel® CoreTM i5 or above/
AMD 1st Generation Ryzen 5 or above.
- Graphics: NVIDIA® GeForce® GTX 900 series and later/
