- 565.2 x 327 x 599.2 mm
- (22.25 x 12.87 x 23.59 inch)
|
|
|
|
|
|
|
|
|
|
- Front(intake): 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1
- Top(exhaust):
- 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1
- Rear(intake):
- 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1
|
|
|
|
|
|
- 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
- 12” x 9.6” (ATX), 12” x 13” (E-ATX)
|
|
- USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 4, HD Audio x 1
|
|
- Standard PS2 PSU (optional)
|
|
- Front:
- 3 x 120mm, 2 x 120mm, 1 x 120mm
- 3 x 140mm, 2 x 140mm, 1 x 140mm
- 2 x 200mm, 1 x 200mm
- Top:
- 2 x 120mm, 1 x 120mm
- 2 x 140mm, 1 x 140mm
- Right (M/B Side):
- 3 x 120mm, 2 x 120mm, 1 x 120mm
- 3 x 140mm, 2 x 140mm, 1 x 140mm
- Rear:
- 3 x 120mm, 2 x 120mm, 1 x 120mm
- 3 x 140mm, 2 x 140mm, 1 x 140mm
- 2 x 200mm, 1 x 200mm
- Bottom:
- 3 x 120mm, 2 x 120mm, 1 x 120mm
- 3 x 140mm, 2 x 140mm, 1 x 140mm
|
|
- Front:
- 1 x 360mm, 1 x 240mm, 1 x 120mm
- 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm
- Top:
- 1 x 240mm, 1 x 120mm
- 1 x 140mm
- Right (M/B Side):
- 1 x 360mm, 1 x 240mm, 1 x 120mm
- 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm
- Rear:
- 1 x 360mm, 1 x 240mm, 1 x 120mm
- 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm
- Bottom:
- 1 x 360mm, 1 x 240mm, 1 x 120mm
- 1 x 280mm, 1 x 140mm
|
|
- CPU cooler max height:
- 190mm
- VGA max length:
- 370mm (With radiator)
- 420mm (Without radiator)
- PSU max length:
- 220mm
|
