Thunderbolt 3 second generation JHL7440 chipset solution
Support DisplayPort DP1.4
Support DisplayPort RBR (Reduced Bit Rate) 、HBR (High Bit Rate) 、HBR2 、HBR3, transmission rate maximum up to 32.4 Gbit/s
Support High Definition Copy Protocol (HDCP2.2)
Support Adaptive Sync (many famous graphic cards build in already)
Support High Dynamic Range HBR(2.7Gbps), HBR2(5.4Gpbs), HBR3(8.1Gbps)
TBT3 host computer under HBR3, adapter support single display resolution maximum up to 8K (7680 x 4320) @30Hz
TBT3 host computer under HBR2, adapter support dual display resolution maximum up to 4K (4096 x 2160) @60Hz or Full HD@144Hz (gamer favorites)
USB3.1 Type-C computer with VESA Alternate Mode under HBR3, adapter support single display resolution maximum up to 5K (5120 x 3200)@30Hz (not recommended for point promotion, cause of many user’s have confusion of Type-C features)
產品介紹
產品規格
Model
WL-UTA21D
Ports
Thunderbolt 3 Type-C
Dual Displayport
Button
NIL
LED
Blue
Power Supply
Bus Power
Power Consumption
4W
DIMENSIONS
Unit Dimensions
99mm(L) x 65mm(W) x 16mm(H)
Housing Material
Aluminum
Shell Color
Apple Gray
FUNCTIONS
Operating System Support
Microsoft Windows10, Mac OSX
Working Standards
Laptop or Desktop with Thunderbolt 3 port
PACKAGE
Update later
1 x Type-C Thunderbolt™ 3 to Dual DisplayPort Display Adapter
