16-bit look-up-table
Digital Uniformity Equalizer
顏色 | Black | ||
面板種類 | IPS | ||
面板尺寸 | 27" / 68.5 cm | ||
最大解析度 | 2560 x 1440 (16:9 aspect ratio) | ||
可視面積 (H × V) | 596.7 x 335.7 mm | ||
點距 | 0.233 × 0.233 mm | ||
顯示色彩 | USB Type-C,DisplayPort, HDMI: 1.07 billion from a palette of 278 trillion DVI: 16.77 million from a palette of 278 trillion |
||
可視角度 | 178°, 178° | ||
亮度 | 350 cd/m2 (maximum) | ||
對比 | 1000:1 | ||
反應時間 | Gray-to-gray: 16 ms | ||
色彩空間 | Adobe RGB: 99% | ||
影像輸入 | USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 1.4), DVI-D (HDCP 1.4) | ||
數位掃瞄頻率 (H, V) | USB Type-C, DisplayPort, DVI: 26 - 89 kHz, 23 - 61 Hz HDMI: 15 - 89 kHz, 23 - 61 Hz |
||
USB | |||
介面 | 上行 USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 60 W max.), Type-B 下行 USB3.1 Gen 1: Type-A x 2, USB 2.0: Type-A x 2 |
||
電源 | AC 100 - 240 V, 50 / 60 Hz | ||
最大功耗 | 34 W (maximum) | ||
標準功耗 | 159 W (maximum) | ||
省電模式 | 1.0 W or less | ||
標準模式 | 1.0 W or less | ||
Digital Uniformity Equalizer | Yes | ||
色彩模式 | Color Mode (User, Adobe RGB, sRGB, Calibration) | ||
OSD 語言 | English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese | ||
其他功能 | Color Adjustment (Brightness, Temperature, Gamma, Color Gamut, Hue, Saturation, Clipping, Gain, Independent 6-Color Control, Reset), Picture Expansion (Auto, Full Screen, Aspect Ratio, Dot by Dot), Input Color Format, Input Range, Noise Reduction, Auto Iuput Detection, Menu Rotation, Power Save, Indicatior, Beep, Input Skip, Mode Skip, Custom Key, USB Selection, Signal Info, Monitor Info, Key Lock, DP Power Save, DUE Priority, Signal Format, Monitor Reset, I/P Conversion, YUV Color Matrix, Information Display | ||
體積 (水平, W x H x D) | 638 x 404.1 - 559.1 x 265 mm | ||
體積 (垂直, W x H x D) | 378.2 x 649 - 689 x 265 mm | ||
重量 | 10.1 kg | ||
高度調整範圍 | 155 mm | ||
傾斜 | 35° Up, 5° Down | ||
擺動 | 344° | ||
旋轉 | 90° | ||
璧孔 (VESA Standard) | 100 x 100 mm | ||
Certifications & Standards (Please contact the EIZO for the latest information.) | CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics | ||
配件 | AC power cord, USB cable, Setup guide,USB Type-C (2 m), HDMI (2 m), Warranty card,VESA mounting screw x 4 | ||
Warranty | Five Years |
