23.8
Screen size (cm)60.5
Flat / CurvedFlat
Display viewing Area (HxW) in mm527,04 x 296,46
Display hardness3H
Panel treatmentAntiglare (AG)
Pixel Pitch (mm)0.2745
Pixels per Inch93
Panel resolution1920x1080
Resolution nameFHD
Aspect ratio16:9
Panel typeIPS
Backlight typeWLED
Max Refresh rate100 Hz
Response time GtG4 ms
Response time MPRT1 ms
Static contrast ratio1300:1
Dynamic contrast ratio20M:1
Viewing angle (CR10)178/178
Display colours16.7M (6bits+FRC)
Brightness in nits250 cd/m2
Color GamutNTSC 72%
OD Response (typical)4 ms GtG
Panel Haze Value25%
Picture enhancement✓
Local Dimming ZonesGlobal Dimming
Adaptive Sync
Digital Signal Frequency Vertical48-100Hz
Digital Signal Frequency Horizontal30-115kHz
HDR (High Dynamic Range)HDR Mode
Blue Light TechnologyLow Blue Light
Colour space (sRGB) CIE 1931 %102.7
Colour space (sRGB) CIE 1976 %102.5
Colour space (DCI-P3) CIE 1931 %75.7
Colour space (DCI-P3) CIE 1976 %81.6
Colour space (Adobe RGB) CIE 1931 %76.1
Colour space (Adobe RGB) CIE 1976 %87.8
Colour space (NTSC) CIE 1931 %72.7
Colour space (NTSC) CIE 1976 %89.4
Colour space (BT 709) CIE 1931 %102.7
Colour space (BT 709) CIE 1976 %102.5
Colour space (BT 2020) CIE 1931 %54.3
Colour space (BT 2020) CIE 1976 %59.5
Flicker-FreeFlicker Free
KVMNo
Ultra Narrow
Bezel Colour (front)Black
Bezel finishing (front)Texture
Cabinet colour (backside)Black
Cabinet finishing (backside)Texture
Removable stand✓
Speakers✓
Speaker power2 W x 2
Kensington Lock✓
Vesa wallmount100x100
I/O define: Connectors on rear cabinetVertical insert
Quick release function✓
Sound enhancementNo
VESA Mount screw SpecM4 x 10
VESA Mount SupportYes
MonitorWebcamNo
-5 (+3/-0) ~ +23 (-3/+0)
Auto Pivot (G sensor)No
No
Energy starEnergy star 8
Post-consumer recycled plasticNo (B2C)
Carton materialPaper
Carton material printWater Print (Brown Carton)
Internal
Power source100 - 240V 50/60Hz
Power consumption on (maximum) in watts130
Power consumption on (typical) in watts30
Power consumption standby in watts0.5
Power consumption off in watts0.3
Power LED indicator (Operation)White/Blue
Power LED indicator (Standby)Orange
HDMI 1.4 x 1
Digital HDCP (HDMI version)HDCP 1.4
USB-C connectivityUSB-C (DP Alt mode) x 1
USB Hub✓
USB Hub speedUSB 3.2 (Gen 1)
USB downstream ports2
USB fast charge port✓
Audio Output1x Audio out
Microphone in✓
mini USB (for external keypad)No
Thunderbolt in0x
Thunderbolt out0x
PD for USB C/TBTUSB C1 : PD=65W, PD3.0, 5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A
USB Hub up stream1 x USB3.2 type C Gen 1, 5 Gbit/s
D-SUB (VGA)0x
DVI0x
RJ45No
542.4 x 412.1 x 202.3
Product dimensions excl. base (WxHxD) mm542.4 x 316.2 x 44.6
Packaging dimensions (WxHxD) mm614 x126 x 394
Packaging dimensions (WxHxD) mm (CN)614 x126 x 394
Gross weight incl. package (in kg)5.28
Net weight excl. package (in kg)3.36
Gross weight incl. package (in kg) (CN)5.28
Product without stand (kg)3.04
1.5
USB-C to C cable1.8
Power Cable✓
4038986141468
OSD languagesEnglish, Ukranian, Turkish, Polish, German, Portuguese, Spanish, French, Finnish, Korean, Japanese, Chinese (simplified), Chinese (traditional), Swedish, Dutch, Italian, Kroatian, Russian, Czech
Warranty period3 years
MTBF30.000 hours (with backlight)
Operation SystemWindows 8.1/10/11, MacOS
OSD typeAOC Gaming
1920 x 1080
Max resolution by input1920 x 1080
Max resolution for USB C/TBT (with USB information)8 bit [email protected] + source HBR2: FHD 100Hz
